M83-LFD1F1N36-0000-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Buying Options
Total Price: USD $30.52
Unit Price: USD $30.52384
≥1 USD $30.52384
≥10 USD $28.79608
≥100 USD $27.166103
≥500 USD $25.628406
≥1000 USD $24.177744
Inventory: 9389
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Technical
Packaging Bag
Published 2012
Series Datamate J-Tek
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 36
Color Black
Number of Rows 3
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 36
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.457 inch
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.415 inch
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Wire Gauge 22 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Durability 500 Cycles
Wire/Cable Gauge 22 AWG
Cable Termination Crimp
Insertion Force-Max 1.0008 N
Withdrawl Force-Min .199882 N
Wire Type Discrete
Contact Design LOOSE
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 12μin
Compliance
RoHS Status ROHS3 Compliant
