M83-LFC1F2N08-0400-325
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
TERMINAL PITCH FOR POWER CONTACT: 4MM Free Hanging Rectangular Connector
PDF
/
Inventory: 1572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 12μin
Contact Finish Thickness 11.8μin 0.30μm
Technical
Contact Arrangement S8P4
Wire Type Discrete
Withdrawl Force-Min .199882 N
Insertion Force-Max 1.0008 N
Cable Termination Crimp
Durability 500 Cycles
Body/Shell Style PLUG
Insulation Resistance 100000000Ohm
Contact Resistance 25mOhm
Rated Current (Signal) 3A
Body Depth 0.415 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Breadth 0.314 inch
Mating Information NS
Operating Temperature (Max) 125°C
Body Length or Diameter 1.141 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2mm
Total Number of Contacts 12
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Additional Feature TERMINAL PITCH FOR POWER CONTACT: 4 MM
Number of Rows 2
Color Black
Number of Positions 12 (8 + 4 Power)
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e4
Series Datamate Mix-Tek
Published 2011
Packaging Bulk
Physical
Mounting Option 1 M2X0.4
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED
