M80-9433405

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 17+17 WAY MALE CRIMP L/BORE W/HOOD
PDF
/
Inventory: 5833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 10.0μin 0.25μm

Technical

Contact Design PREASSEM CONN
Wire Type Discrete
Withdrawl Force-Min .1946 N
Cable Termination Crimp
Wire/Cable Gauge 22 AWG
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 22 AWG
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 34
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature ROHS COMPLIANT
Gender Male
Number of Rows 2
Color Black
Number of Positions 34
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Cable Hood Kit, Jackscrews
JESD-609 Code e4
Series Datamate J-Tek
Published 2013
Packaging Bulk

Physical

Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material BRASS

Supply Chain

Factory Lead Time 16 Weeks
