M80-8981705
RoHS
RoHS compliant
RoHS compliantPackage SIL
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 17POS CRIMP 24-28AWG
PDF
/
Buying Options
Total Price: USD $10.28
Unit Price: USD $10.2784
≥1 USD $10.2784
≥10 USD $9.11328
≥100 USD $8.762336
≥500 USD $8.41192
≥1000 USD $7.94464
≥3000 USD $7.243632
Inventory: 71
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Brass
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case SIL
Housing Material Polyester
Technical
Packaging Bulk
Published 2012
Series Datamate L-Tek
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 17
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Additional Feature ROHS COMPLIANT
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 17
Orientation Straight
Depth 8.15mm
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Lead Pitch 2mm
Contact Gender Female
UL Flammability Code 94V-0
Working Voltage 120V
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Wire Gauge 24-28 AWG
Max Voltage Rating (AC) 120V
Max Current Rating 3A
Polarization Key POLARIZED HOUSING
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 500 Cycles
Wire/Cable Gauge 24 AWG
Cable Termination Crimp
Insertion Force-Max 2.78 N
Wire Type Discrete
Dimensions
Length 37.15mm
Contact Finish Thickness 11.8μin 0.30μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
