M80-8450545

Harwin Inc.
RoHS
RoHS RoHS compliant
Package SIL
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Conn Datamate SKT 5 POS 2mm Crimp ST Cable Mount Bag
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.6256
≥1 USD $3.6256
≥10 USD $3.29032
≥100 USD $3.116608
≥500 USD $3.044272
≥1000 USD $2.899248
≥3000 USD $2.536864
Inventory: 554
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 11.8μin 0.30μm
Length 13.15mm

Technical

Contact Design PREASSEM CONN
Wire Type Discrete
Insertion Force-Max 2.78 N
Cable Termination Crimp
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Wire Gauge 24-28 AWG
Contact Resistance 25mOhm
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Reach Compliance Code not_compliant
Depth 8.15mm
Orientation Straight
Total Number of Contacts 5
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Additional Feature ROHS COMPLIANT
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 5
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Datamate L-Tek
Published 2011
Packaging Bulk

Physical

Housing Material Polyamide
Package / Case SIL
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 9 Weeks
