M80-7981701
RoHS
RoHS compliant
RoHS compliantPackage SIL
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 7636
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case SIL
Insulation Material GLASS FILLED POLYAMIDE
Technical
Packaging Bulk
Published 2013
Series Datamate L-Tek
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 17
Color Black
Number of Rows 1
HTS Code 8536.69.40.40
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 17
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Wire Gauge 28-32 AWG
Polarization Key POLARIZED HOUSING
Wire Gauge (Max) 32 AWG
Wire Gauge (Min) 28 AWG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Compliance
RoHS Status ROHS3 Compliant
