M80-7980701

Harwin Inc.
RoHS
RoHS RoHS compliant
Package SIL
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Datamate L-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 32AWG 25mOhm -55C
PDF
/
Inventory: 986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 11.8μin 0.30μm

Technical

Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 32 AWG
Polarization Key POLARIZED HOUSING
Wire Gauge 28-32 AWG
Contact Resistance 25mOhm
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 7
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
Number of Positions 7
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Datamate L-Tek
Published 2013
Packaging Bulk

Physical

Insulation Material GLASS FILLED POLYAMIDE
Package / Case SIL
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 13 Weeks
