M80-7184205
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Power to the Board 42S+2P S/BORE CRIMP CONN
PDF
/
Inventory: 7635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material BERYLLIUM COPPER
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material POLYAMIDE46
Shell Material COPPER ALLOY
Technical
Packaging Bulk
Published 2005
Series Datamate Mix-Tek
JESD-609 Code e4
Feature Mounting Flange, Potting Wall
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 44 (42 + 2 Power)
Color Black
Gender Male
Additional Feature POLARIZED, SHROUDED
HTS Code 8536.69.40.30
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 44
Current Rating 10A
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.618 inch
Operating Temperature (Max) 125°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.334 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.37 inch
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Insulation Resistance 100000000Ohm
Durability 500 Cycles
Cable Termination Crimp
Insertion Force-Max 2.78 N
Withdrawl Force-Min .199882 N
Wire Type Discrete
Contact Arrangement S42P2
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 12μin
Compliance
RoHS Status ROHS3 Compliant
