M80-7182401A
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 9410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Insulation Material POLYAMIDE
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Series Datamate Mix-Tek
JESD-609 Code e3
Feature Mounting Flange
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 26 (24 + 2 Power)
Color Black
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Contact Type Female Socket
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 26
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.146 inch
Operating Temperature (Max) 125°C
Body Breadth 0.334 inch
Operating Temperature (Min) -55°C
Body Depth 0.37 inch
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Insulation Resistance 100000000Ohm
Durability 500 Cycles
Cable Termination Crimp
Insertion Force-Max 2.78 N
Withdrawl Force-Min .199882 N
Wire Type Discrete
Contact Arrangement S24P2
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 12μin
Compliance
RoHS Status Non-RoHS Compliant
