M80-7182401
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate Mix-Tek Non-RoHS Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 2.78N 25mOhm 125C
PDF
/
Inventory: 6264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 12μin
Contact Finish Thickness 11.8μin 0.30μm
Technical
Contact Arrangement S24P2
Wire Type Discrete
Withdrawl Force-Min .199882 N
Insertion Force-Max 2.78 N
Cable Termination Crimp
Durability 500 Cycles
Insulation Resistance 100000000Ohm
Contact Resistance 25mOhm
Rated Current (Signal) 3A
Body Depth 0.37 inch
Operating Temperature (Min) -55°C
Body Breadth 0.334 inch
Operating Temperature (Max) 125°C
Body Length or Diameter 1.146 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 26
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Female Socket
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Color Black
Number of Positions 26 (24 + 2 Power)
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Mounting Flange, Potting Wall
Series Datamate Mix-Tek
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material POLYAMIDE
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED
