M80-7180605
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Power to the Board 6S+2P S/BORE CRIMP CONN
PDF
/
Inventory: 4026
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 12μin
Contact Finish Thickness 11.8μin 0.30μm
Technical
Contact Arrangement S6P2
Wire Type Discrete
Withdrawl Force-Min .199882 N
Insertion Force-Max 2.78 N
Cable Termination Crimp
Durability 500 Cycles
Insulation Resistance 100000000Ohm
Contact Resistance 25mOhm
Rated Current (Signal) 3A
Body Depth 0.37 inch
Empty Shell NO
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Breadth 0.334 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 125°C
Body Length or Diameter 0.673 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 10A
Total Number of Contacts 8
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature POLARIZED, SHROUDED
Gender Male
Color Black
Number of Positions 8 (6 + 2 Power)
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Mounting Flange, Potting Wall
JESD-609 Code e4
Series Datamate Mix-Tek
Published 2005
Packaging Bulk
Physical
Shell Material COPPER ALLOY
Insulation Material POLYAMIDE46
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material BERYLLIUM COPPER
