M80-7086305
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 63 POS FEMALE W/ JACKSCREWS
PDF
/
Inventory: 5282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Panel
Mounting Type Panel Mount
Shell Material PLASTIC
Housing Material Polyamide
Technical
Packaging Tray
Published 2006
Series Datamate J-Tek
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 63
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 3
Voltage - Rated 360V
Additional Feature POLARIZED, SHROUDED
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 63
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 2.169 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-0
Empty Shell NO
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Wire Gauge 24-28 AWG
Insulation Resistance 100MOhm
Row Spacing 0.079 (2.00mm)
Body/Shell Style PLUG
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 500 Cycles
Cable Termination Crimp
Insertion Force-Max 2.78 N
Withdrawl Force-Min .199882 N
Wire Type Discrete
Dimensions
Plating Thickness 12μin
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
