M80-7065105
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 51 WAY L/BORE CRIMP CONN +J/S
PDF
/
Buying Options
Total Price: USD $27.55
Unit Price: USD $27.5528
≥1 USD $27.5528
≥10 USD $24.12887
≥100 USD $21.597083
≥500 USD $19.809689
Inventory: 96
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Brass
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYETHYLENE
Shell Material POLYAMIDE46
Technical
Packaging Tray
Published 2001
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 51
Number of Rows 3
Additional Feature POLARIZED, SHROUDED
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 51
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.854 inch
Operating Temperature (Max) 125°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.247 inch
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Wire Gauge 22 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Durability 500 Cycles
Wire/Cable Gauge 22 AWG
Cable Termination Crimp
Insertion Force-Max 2.78 N
Withdrawl Force-Min .199882 N
Wire Type Discrete
Contact Design LOOSE
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 12μin
Compliance
RoHS Status ROHS3 Compliant
