M80-5631805

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 9+9 WAY MALE CRIMP S/BORE+REV FIX JS
PDF
/
Inventory: 942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Contact Gender Male
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.309 inch
Rated Current (Signal) 3A
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Reach Compliance Code not_compliant
Total Number of Contacts 18
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Additional Feature COMPATIBLE CONTACT: M80-1950005, PANEL MOUNTABLE
Number of Rows 2
Color Black
Number of Positions 18
Connector Type Header
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e4
Series Datamate J-Tek
Published 2013
Packaging Bulk
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Polarization Key POLARIZED HOUSING

Physical

Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 10 Weeks

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 10.0μin 0.25μm
