M80-5624205
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 21+21 WAY MALE CRIMP L/BORE+REV FIX JS
PDF
/
Buying Options
Total Price: USD $26.59
Unit Price: USD $26.5879
≥1 USD $26.5879
≥10 USD $25.082922
≥100 USD $23.663132
≥500 USD $22.323714
≥1000 USD $21.060109
Inventory: 1722
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Technical
Packaging Bulk
Published 2013
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Header
Number of Positions 42
Color Black
Number of Rows 2
Additional Feature COMPATIBLE CONTACT: M80-1940005, PANEL MOUNTABLE
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 42
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Contact Gender Male
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.309 inch
Rated Current (Signal) 3A
Wire Gauge 22 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Polarization Key POLARIZED HOUSING
Durability 500 Cycles
Wire/Cable Gauge 22 AWG
Cable Termination Crimp
Wire Type Discrete
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
