M80-5615005

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 25+25 POS MALE 24-28 AWG W/JACKSCRW
PDF
/
Buying Options
Total Price: USD $36.5
Unit Price: USD $36.5024
≥1 USD $36.5024
≥10 USD $31.96072
≥100 USD $30.579648
≥500 USD $29.592992
≥1000 USD $28.6066
≥3000 USD $27.02832
Inventory: 79
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Material Brass
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyphenylene

Technical

Packaging Bulk
Published 2011
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Header
Number of Positions 50
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Voltage - Rated 360V
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 50
Orientation Straight
Depth 6.05mm
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Contact Gender Male
UL Flammability Code 94V-0
Contact Resistance 25mOhm
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style RECEPTACLE
Max Voltage Rating (AC) 120V
Max Current Rating 3A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Cable Termination Crimp
Wire Type Discrete
Insulation Diameter-Min 0.043 inch

Dimensions

Length 60mm
Contact Finish Thickness 10.0μin 0.25μm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
