M80-5612605
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 13+13 WAY MALE CRIMP L/Bore + JS
PDF
/
Buying Options
Total Price: USD $21.42
Unit Price: USD $21.4192
≥1 USD $21.4192
≥10 USD $18.75984
≥100 USD $16.79128
Inventory: 79
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material BRASS
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyphenylene
Technical
Packaging Bulk
Published 2011
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Header
Number of Positions 26
Color Black
Number of Rows 2
Voltage - Rated 360V
Additional Feature COMPATIBLE CONTACTS: M80-1940005; M80-1950005, POLARIZATION AVAILABLE
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 26
Current Rating 3A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.417 inch
Contact Gender Male
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.309 inch
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style RECEPTACLE
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Insulation Diameter-Min 0.043 inch
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
