M80-5000000M3-02-331-00-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
ROHS COMPLIANT Free Hanging Rectangular Connector
PDF
/
Buying Options
Total Price: USD $31.79
Unit Price: USD $31.7944
≥1 USD $31.7944
≥10 USD $27.842575
≥100 USD $24.920738
Inventory: 74
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Wire Type Coaxial
Withdrawl Force-Min .5004 N
Cable Termination Crimp
Durability 500 Cycles
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Contact Resistance 6mOhm
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Length or Diameter 0.709 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 2
Pitch 0.157 4.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin, Coaxial
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
Additional Feature ROHS COMPLIANT
Number of Rows 1
Color Black
Number of Positions 2
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews, Polarizing Key
Series Datamate Mix-Tek
Published 2015
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Panel Mount
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
