M80-4E13405F2

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Datamate J-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 32AWG -55C 11.8muin 0.30mum
PDF
/
Inventory: 5393
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Plating Thickness 11μin
Contact Finish Thickness 11.8μin 0.30μm

Technical

Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 32 AWG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 28-32 AWG
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 34
Pitch 0.079 2.00mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Black
Number of Positions 34
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
Series Datamate J-Tek
Published 2012
Packaging Bulk

Physical

Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 9 Weeks
