M80-4E11205F2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate J-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 32AWG -55C 0.866inch
PDF
/
Inventory: 4285
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Technical
Packaging Bulk
Published 2012
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 12
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.079 2.00mm
Total Number of Contacts 12
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.866 inch
Operating Temperature (Min) -55°C
Wire Gauge 28-32 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Wire Gauge (Max) 32 AWG
Wire Gauge (Min) 28 AWG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 11μin
Compliance
RoHS Status ROHS3 Compliant
