M80-4C10642F2-00-000-04-32D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 3458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Wire Type Discrete
Withdrawl Force-Min .1946 N
Cable Termination Crimp
Durability 500 Cycles
Body/Shell Style PLUG
Insulation Resistance 100000000Ohm
Rated Current (Signal) 3A
Body Depth 0.5 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Length or Diameter 0.787 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code compliant
Total Number of Contacts 10
Option GENERAL PURPOSE
Mixed Contacts YES
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Number of Positions 10 (6 + 4 Power)
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Jackscrews, Polarizing Key
JESD-609 Code e3
Series Datamate Mix-Tek
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED
