M80-4862605A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
COMPATIBLE CONTACT: M80-0130005 Free Hanging Rectangular Connector
PDF
/
Buying Options
Total Price: USD $32.41
Unit Price: USD $32.405923
≥1 USD $32.405923
≥10 USD $30.571625
≥100 USD $28.841155
≥500 USD $27.208641
≥1000 USD $25.668524
Inventory: 1519
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Technical
Contact Design LOOSE
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 24-28 AWG
Rated Current (Signal) 3A
Body Depth 0.337 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Length or Diameter 1.417 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 26
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Additional Feature COMPATIBLE CONTACT: M80-0130005
Number of Rows 2
Color Black
Number of Positions 26
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews, Polarizing Key, Potting Wall
JESD-609 Code e4
Series Datamate J-Tek
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Contact Material BERYLLIUM COPPER
Supply Chain
Factory Lead Time 13 Weeks
