M80-4813642
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate J-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles -55C 1.811inch
PDF
/
Inventory: 9905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 11μin
Contact Finish Thickness 11.8μin 0.30μm
Technical
Insulation Diameter-Min 0.043 inch
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 24-28 AWG
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Length or Diameter 1.811 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Reach Compliance Code not_compliant
Total Number of Contacts 36
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature COMPATABLE CONTACT: M80-0130001, PANEL MOUNTABLE
Number of Rows 2
Color Black
Number of Positions 36
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e3
Series Datamate J-Tek
Published 2011
Packaging Tube
Physical
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Contact Material NOT SPECIFIED
