M80-4813605
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
COMPATABLE CONTACT: M80-0130005PANEL MOUNTABLE Free Hanging Rectangular Connector
PDF
/
Inventory: 3558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Technical
Packaging Tube
Published 2011
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 36
Color Black
Number of Rows 2
Additional Feature COMPATABLE CONTACT: M80-0130005, PANEL MOUNTABLE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 36
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.811 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style PLUG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Insulation Diameter-Min 0.043 inch
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 11μin
Compliance
RoHS Status ROHS3 Compliant
