M80-4810642
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 3+3 WAY FMALE CRMP S/BORE W/HEX JS
PDF
/
Buying Options
Total Price: USD $14.6
Unit Price: USD $14.5992
≥1 USD $14.5992
≥10 USD $12.93776
≥100 USD $12.440384
≥500 USD $11.942832
≥1000 USD $11.279312
≥3000 USD $10.284067
Inventory: 593
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Plating Thickness 11μin
Contact Finish Thickness 11.8μin 0.30μm
Length 16mm
Technical
Insulation Diameter-Min 0.043 inch
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Max Current Rating 3A
Max Voltage Rating (AC) 120V
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 24-28 AWG
Contact Resistance 25mOhm
UL Flammability Code 94V-0
Contact Gender Female
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Orientation Straight
Total Number of Contacts 6
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature COMPATABLE CONTACT: M80-0130001, PANEL MOUNTABLE
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 6
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e3
Series Datamate J-Tek
Published 2011
Packaging Bulk
Physical
Housing Material Polyphenylene
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
