M80-4802242

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description PANEL MOUNTABLE Free Hanging Rectangular Connector
PDF
/
Inventory: 9353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material NOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Option 1 LOCKING

Technical

Packaging Tube
Published 2013
Series Datamate J-Tek
JESD-609 Code e3
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Contact Design LOOSE
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 22 AWG
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Reach Compliance Code not_compliant
Total Number of Contacts 22
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature PANEL MOUNTABLE
Number of Rows 2
Color Black
Number of Positions 22

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 11.8μin 0.30μm
