M80-4712405
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate J-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles -55C 3A 1.339inch
PDF
/
Inventory: 2021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Option 1 LOCKING
Mounting Option 2 JACKSCREW
Technical
Packaging Bulk
Series Datamate J-Tek
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 24
Color Black
Number of Rows 2
Additional Feature COMPATIBLE CONTACT: M80-0130005
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 24
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.339 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style PLUG
Polarization Key POLARIZED HOUSING
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Contact Design LOOSE
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Compliance
RoHS Status ROHS3 Compliant
