M80-4661042A

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description COMPATIBLE CONTACT: M80-0130001 Rectangular Connector Panel Mount
PDF
/
Inventory: 1791
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 11.8μin 0.30μm

Technical

Contact Design LOOSE
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Row Spacing 0.079 (2.00mm)
Wire Gauge 24-28 AWG
Rated Current (Signal) 3A
Body Depth 0.337 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Body Length or Diameter 0.787 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 10
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Additional Feature COMPATIBLE CONTACT: M80-0130001
Number of Rows 2
Color Black
Number of Positions 10
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews, Polarizing Key
JESD-609 Code e3
Series Datamate J-Tek
Packaging Bulk

Physical

Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Contact Material BERYLLIUM COPPER

Supply Chain

Factory Lead Time 13 Weeks
