M80-4633405

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RCPT 34POS CRIMP 24-28AWG
PDF
/
Inventory: 2932
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material NOT SPECIFIED
Mount Panel
Mounting Type Panel Mount
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE

Technical

Packaging Bulk
Published 2011
Series Datamate J-Tek Reverse Fix
JESD-609 Code e4
Feature Jackscrews, Polarizing Key
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 34
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
Fastening Type Screw Lock
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 34
Reach Compliance Code not_compliant
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Contact Gender Female
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Wire Gauge 24-28 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style PLUG
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 24 AWG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Insulation Diameter-Min 0.043 inch

Dimensions

Contact Finish Thickness 11.8μin 0.30μm
Plating Thickness 11μin

Compliance

RoHS Status ROHS3 Compliant
