M80-4611842
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate J-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 28AWG -55C 3A
PDF
/
Inventory: 8158
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Technical
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 24-28 AWG
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Female
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Reach Compliance Code not_compliant
Total Number of Contacts 18
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature COMPATIBLE CONTACT: M80-0130001, PANEL MOUNTABLE
Number of Rows 2
Color Black
Number of Positions 18
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e3
Series Datamate J-Tek
Published 2011
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 11 Weeks
