M80-4601642

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 8+8 WAY FEMALE CRIMP L/BORE W/JS
PDF
/
Buying Options
Total Price: USD $18.15
Unit Price: USD $18.1544
≥1 USD $18.1544
≥10 USD $15.89896
≥100 USD $15.212032
≥500 USD $14.721168
≥1000 USD $14.23048
≥3000 USD $13.445344
Inventory: 162
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 11.8μin 0.30μm

Technical

Contact Design LOOSE
Wire Type Discrete
Cable Termination Crimp
Wire/Cable Gauge 22 AWG
Durability 500 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 22 AWG
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 16
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature PANEL MOUNTABLE, COMPATIBLE CONTACTS: M80-0110001
Number of Rows 2
Color Black
Number of Positions 16
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews, Polarizing Key
JESD-609 Code e3
Series Datamate J-Tek
Published 2013
Packaging Bulk

Physical

Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 12 Weeks
