M80-4000000FP-06-306-00-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate Mix-Tek RoHS Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 4.8928N -55C 0.297inch
PDF
/
Inventory: 4907
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Pitch 0.157 4.00mm
Total Number of Contacts 6
Reach Compliance Code compliant
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.297 inch
Body/Shell Style PLUG
Durability 500 Cycles
Cable Termination Crimp
Insertion Force-Max 4.8928 N
Wire Type Coaxial
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket, Coaxial
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
Number of Rows 1
Color Black
Number of Positions 6
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Guide, Polarizing Key
Series Datamate Mix-Tek
Packaging Bulk
Compliance
RoHS Status RoHS Compliant
Physical
Mounting Option 2 JACKSCREW
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Panel Mount
Contact Material NOT SPECIFIED
