M80-4000000FE-02-32A-00-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate Mix-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 8.0064N 6mOhm -55C
PDF
/
Inventory: 6135
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Panel Mount, Right Angle
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Option 1 GUIDE PIN
Mounting Option 2 LOCKING
Technical
Packaging Bulk
Published 2015
Series Datamate Mix-Tek
Feature Jackscrews
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 2
Color Black
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket, Power
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.157 4.00mm
Total Number of Contacts 2
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.709 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.445 inch
Contact Resistance 6mOhm
Wire Gauge 12 AWG
Body/Shell Style PLUG
Durability 500 Cycles
Cable Termination Solder
Insertion Force-Max 8.0064 N
Withdrawl Force-Min .5004 N
Wire Type Discrete
Compliance
RoHS Status ROHS3 Compliant
