0918526781358U
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 8555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Series SEK
Feature Feed Through, Polarizing Key, Strain Relief
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 26
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU
Contact Type Female Socket
Pitch 0.100 2.54mm
Total Number of Contacts 26
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.48 inch
Operating Temperature (Min) -55°C
Rated Current (Signal) 2A
Wire Gauge 26-28 AWG
Insulation Resistance 1000000000Ohm
Row Spacing 0.100 (2.54mm)
Termination Type IDC
Polarization Key CENTER
Wire/Cable Type Ribbon
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 26 AWG
Durability 50 Cycles
Cable Termination IDC
Wire Type Ribbon Cable
Contact Design PREASSEM CONN
Compliance
RoHS Status ROHS3 Compliant
