CWR-217-26-0003
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN SOCKET 26PIN TIN W/KEY/STR
PDF
/
Inventory: 2154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 100.0μin 2.54μm
Width 6.1mm
Length 37.5mm
Height 14.8mm
Technical
Wire Size (Min) 30 AWG
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 500VDC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Rated Current (Signal) 1A
Operating Temperature (Min) -55°C
Reliability COMMERCIAL
Contact Finish Tin-Lead
Reference Standard UL, CSA
Total Number of Contacts 26
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Blue
Number of Positions 26
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through, Polarizing Key, Strain Relief
Series CWR
Published 2002
Packaging Bulk
Physical
Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 8 Weeks
