009286004121506
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN JUNCT 4POS POKE-IN 18-26AWG
PDF
/
Inventory: 5157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 8.8mm
Technical
Wire Type Discrete
Cable Termination Poke-In
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 26 AWG
Max Voltage Rating (AC) 250V
Wire Gauge 18-26 AWG
Contact Gender Female
Contact Finish Tin
Current Rating 10A
Depth 17mm
Orientation Straight
Pitch 4mm
Contact Type Spring
Voltage - Rated 300V
Number of Rows 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Positions 4
Connector Type Junction Box
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
Series 9286
Packaging Cut Tape (CT)
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze, Copper
