AWP26-8540-T-R
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 4564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 7mm
Length 38mm
Height 7mm
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Dielectric Withstanding Voltage 500VAC V
Termination Type IDC
Body/Shell Style PLUG
Row Spacing 0.100 (2.54mm)
Insulation Resistance 3000000000Ohm
Contact Resistance 30mOhm
Rated Current (Signal) 1A
Housing Color Grey
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Number of Contacts 26
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Gray
Connector Type Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
Published 2006
Packaging Tray
Physical
Mounting Option 1 LOCKING
Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Contact Material Brass
