AWH60G-E232-IDC-R
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PIN IDC 60POS W/ FLANGE
PDF
/
Inventory: 6139
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Mount Panel
Mounting Type Panel Mount
Housing Material Plastic
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 100μin
Width 8.2mm
Length 111mm
Height 19.1mm
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Rated Current (Signal) 3A
Body Depth 0.756 inch
Housing Color Grey
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 60
Pitch 0.100 2.54mm
Contact Type Male Pin
Fastening Type Latch Lock/Eject Hooks, Long
Number of Rows 2
Color Gray
Number of Positions 60
Connector Type Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Feed Through
Published 2006
Packaging Tray
