AWH16G-E232-IDC-R
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PIN IDC 16POS W/ FLANGE
PDF
/
Inventory: 3382
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 100μin
Width 8.2mm
Length 54.9mm
Height 19.1mm
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Wire/Cable Type Ribbon
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Body/Shell Style RECEPTACLE
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Rated Current (Signal) 3A
Body Depth 0.756 inch
Housing Color Grey
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 16
Pitch 0.100 2.54mm
Contact Type Male Pin
Fastening Type Latch Lock/Eject Hooks, Long
HTS Code 8536.69.40.40
Number of Rows 2
Color Gray
Number of Positions 16
Connector Type Header
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
Packaging Tray
Physical
Housing Material Plastic
Mounting Type Panel Mount
Mount Panel
Contact Material Brass
