66245-040LF
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Conn IDC Connector RCP 40 POS 2.54mm IDT RA Cable Mount Tube
PDF
/
Inventory: 7025
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyester
Technical
Packaging Tube
Published 2006
Series Quickie?
Feature Closed End
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDT
Connector Type Receptacle
Number of Positions 40
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Blue
Number of Rows 2
Contact Type Female Socket
Pitch 0.100 2.54mm
Orientation Right Angle
Depth 14mm
Contact Finish Gold
Contact Resistance 15mOhm
Wire Gauge 28-30 AWG
Max Voltage Rating (AC) 1kV
Wire/Cable Type Ribbon
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 28 AWG
Cable Termination IDC
Wire Type Ribbon Cable
Dimensions
Length 55.37mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status RoHS Compliant
