MTD-A-05-D-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
MTD ROHS3Compliant COMMERCIAL UL CSA Receptacle Rectangular Connector -40C 4A 0.272inch
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.6512
≥1 USD $0.6512
≥10 USD $0.55
≥100 USD $0.527648
≥500 USD $0.51656
≥1000 USD $0.494032
≥3000 USD $0.449117
Inventory: 653
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Termination Type IDC
Wire Gauge 24 AWG
Rated Current (Signal) 4A
UL Flammability Code 94V-2
Operating Temperature (Min) -40°C
Body Breadth 0.272 inch
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL, CSA
Total Number of Contacts 5
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Number of Rows 1
Color White
Number of Positions 5
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through
JESD-609 Code e3
Series MTD
Packaging Bulk
Physical
Insulation Material NYLON
Mounting Type Free Hanging (In-Line), Right Angle
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 9 Weeks
