FCS-60-SG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
SOCKET FLAT CABLE IDC 60P 2.54MM
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $1.07272
≥100 USD $1.02667
≥500 USD $1.00393
≥1000 USD $0.958223
Inventory: 181
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.07 inch
Contact Finish Thickness Flash
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.100 (2.54mm)
Insulation Resistance 100000000Ohm
Contact Resistance 1000mOhm
Rated Current (Signal) 1A
Operating Temperature (Min) -40°C
Body Breadth 0.165 inch
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Total Number of Contacts 60
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Number of Rows 2
Color Black
Number of Positions 60
Connector Type Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through, Polarizing Key
Series FCS
Packaging Tray
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Type Free Hanging (In-Line)
Contact Material BRASS
Supply Chain
Factory Lead Time 9 Weeks
