FCS-26-SG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 26 pos. IDC Socket Dual Row
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.6732
≥100 USD $0.64592
≥500 USD $0.63206
≥1000 USD $0.604578
≥3000 USD $0.549648
Inventory: 461
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness Flash
Technical
Wire Size (Min) 30 AWG
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Withdrawl Force-Min .1946 N
Cable Termination IDC
Durability 500 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Body/Shell Style PLUG
Row Spacing 0.100 (2.54mm)
Insulation Resistance 3000000000Ohm
Rated Current (Signal) 1A
Operating Temperature (Min) -40°C
Body Breadth 0.165 inch
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Current Rating 1A
Total Number of Contacts 26
Pitch 0.100 2.54mm
Contact Type Female Socket
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Voltage - Rated 250V
Gender Female
Number of Rows 2
Color Black
Number of Positions 26
Connector Type Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through, Polarizing Key
JESD-609 Code e3
Series FCS
Packaging Tray
Physical
Mounting Option 1 LOCKING
Housing Material PBT
Mounting Type Free Hanging (In-Line)
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 10 Weeks
