2FCS-20-SG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.63976
≥100 USD $0.613536
≥500 USD $0.60038
≥1000 USD $0.574279
≥3000 USD $0.522078
Inventory: 496
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.07 inch
Contact Finish Thickness Flash
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Contact Resistance 1000mOhm
Rated Current (Signal) 1A
Operating Temperature (Min) -40°C
Body Breadth 0.165 inch
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Current Rating 1A
Total Number of Contacts 20
Pitch 0.079 2.00mm
Contact Type Female Socket
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Voltage - Rated 250V
Gender Female
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through
Series 2FCS
Packaging Tray
Physical
Mounting Option 1 LOCKING
Housing Material PBT
Mounting Type Free Hanging (In-Line)
Contact Material Bronze
Supply Chain
Factory Lead Time 9 Weeks
