CHG-1004-001010-KCP

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN RCPT 4POS IDC 26-28AWG GOLD
PDF
/
Buying Options
Total Price: USD $13.57
Unit Price: USD $13.57276
≥1 USD $13.57276
≥200 USD $5.415713
≥500 USD $5.234532
≥1000 USD $5.145255
Inventory: 1155
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 3m

Technical

Wire Type Discrete or Ribbon Cable
Sensing Distance 3 m
Cable Termination IDC
Cable Length 3m
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Discrete
Wire Gauge 26-28 AWG
Lead Length 3m
Housing Color Grey
Contact Gender Female
Number of Contacts 4
Approval Agency UL
Contact Finish Gold
Current Rating 1.5A
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Gender Female
Number of Rows 1
Color Gray
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End
Series CHG
Published 2009
Packaging Bulk

Physical

Weight 453.59237g
Housing Material Glass
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Gold

Supply Chain

Factory Lead Time 6 Weeks
