3626-7624

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 24 CON WIREMNT SKT 3WALL CLSD END
PDF
/
Buying Options
Total Price: USD $5.68
Unit Price: USD $5.676
≥1 USD $5.676
≥10 USD $5.13392
≥100 USD $4.021864
≥500 USD $3.312126
Inventory: 170
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Width 6.1mm
Length 35.1mm
Height 13.7mm

Technical

Wire Type Ribbon Cable
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG
Housing Color Grey
Contact Gender Female
Contact Finish Gold
Pitch 0.100 2.54mm
Contact Type Female Socket
Gender Female
Number of Rows 2
Color Black
Number of Positions 24
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed End, Polarizing Key, Strain Relief
Series 3000
Published 2009
Packaging Bulk

Physical

Weight 612.3497g
Housing Material PBT
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold

Supply Chain

Factory Lead Time 6 Weeks
