3417-H600
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 40/SKT/PRA SB/OP/CB/ CA.REC.EVEN RW/30AVG
PDF
/
Buying Options
Total Price: USD $15.77
Unit Price: USD $15.774494
≥1 USD $15.774494
≥200 USD $6.294043
≥500 USD $6.083979
≥1000 USD $5.98026
Inventory: 5823
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 55.4mm
Technical
Wire Type Ribbon Cable
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Wire/Cable Type Ribbon
Max Current Rating 1A
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG, Stranded or Solid
Housing Color Grey
Number of Contacts 40
Contact Finish Gold
Current Rating 1A
Depth 6.1mm
Orientation Right Angle
Pitch 0.100 2.54mm
Contact Type Female Socket
Gender Female
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 40
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through, Polarizing Key
Series 3000
Published 2011
Packaging Bulk
Physical
Weight 3.175147kg
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Gold
Supply Chain
Factory Lead Time 6 Weeks
