152220-0010-GB

3M
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description 1522 RoHS Compliant Closed End Polarizing Key Female Receptacle Rectangular Connector 28AWG 30.0muin 0.76mum
PDF
/
Inventory: 6049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Series 1522
Feature Closed End, Polarizing Key
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 20
Color Gray
Number of Rows 2
Gender Female
Contact Type Female Socket
Pitch 0.079 2.00mm
Contact Finish Gold
Wire Gauge 28 AWG
Row Spacing 0.079 (2.00mm)
Wire/Cable Type Ribbon
Wire/Cable Gauge 28 AWG
Cable Termination IDC
Wire Type Ribbon Cable

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Compliance

RoHS Status RoHS Compliant
