926869-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description TE CONNECTIVITY / AMP 926869-3Contact, Universal MATE-N-LOK Series, Socket, 16 AWG, 13 AWG, Crimp, Phosphor Bronze
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.18656
≥100 USD $0.173184
≥500 USD $0.164208
≥1000 USD $0.15532
≥3000 USD $0.144566
Inventory: 17743
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Material Bronze
Mount Cable

Technical

Packaging Tape & Reel (TR)
Published 1997
Series Universal MATE-N-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Gender Receptacle
Voltage - Rated 600V
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 6.35mm
Orientation Straight
Depth 5.8mm
Current Rating 19A
Contact Finish Tin
Voltage - Rated AC 600V
Approval Agency UL
Contact Gender Female
Wire Gauge 13-15 AWG
ELV Compliant
Max Current Rating 19A
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 13 AWG
Wire Gauge (Min) 15 AWG
Wire/Cable Gauge 13 AWG
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 5.08 mm
Wire/Cable Diameter 5.1 mm
Pin or Socket Socket
Assembly Item Name CONTACT
VDE Tested Yes
Cable Entry-Max 0.2 inch
Cable Entry-Min 0.13 inch

Dimensions

Height 5.8mm
Length 20.6mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Not Applicable
