87523-7 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings MOD IV RECP LP
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.626698
≥1 USD $0.626698
≥10 USD $0.591218
≥100 USD $0.557751
≥500 USD $0.526184
≥1000 USD $0.4964
Inventory: 7318
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 24 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Contact Material Bronze, Copper, Tin
Mount Cable

Technical

Packaging Bulk
Published 2006
Series AMPMODU Mod IV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -65°C
HTS Code 8536.90.40.00
Orientation Straight
Shielding Unshielded
Depth 2.41mm
Current Rating 3A
Contact Finish Gold
Voltage - Rated AC 250V
Approval Agency CSA
Contact Gender Female
Operating Supply Voltage 250V
Contact Resistance 12mOhm
Wire Gauge 20-24 AWG
Insulation Resistance 5GOhm
ELV Compliant
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 24 AWG
Contact Current Rating 3A
Contact Termination Crimp
Insulation Diameter 1.75 mm
Pin or Socket Socket

Dimensions

Height 2.03mm
Length 12.09mm
Contact Finish Thickness 15.0μin 0.38μm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
